Structural Adhesive Series
Usage
Structural Adhesives are formulated to provide excellent mechanical resistance, including high shear strength, peel resistance, and impact resistance—particularly for metal bonding applications. They are single-component systems with a simple two-step operation: a pre-applied activator eliminates the need for mixing or ratio control. With a quick fixture time at room temperature, they offer an efficient, reliable, and weather-resistant bonding solution.
Characteristics
- Mid-high viscosity, single compound, anaerobic type, bigger gap bonding
- Durable, impact-resistant, high-strength, and chemical-resistant properties.
- With high strength and fast fixture time.
- For large gaps (0.5~1 mm).
- It is suitable for bonding most metals and ferrites and can also be used on some plastic materials. Volume: 50 ml / 1000 ml
- Mid-high viscosity, single compound, anaerobic type, fast curing on metals
- Durable, impact-resistant, high-strength, and chemical-resistant properties.
- With high strength and fast fixture time. For gaps smaller than 0.25 mm. Curing time is within 2 minutes.
- Good adhesion on different types of ferrites, such as permanent magnets, transformer cores, and other applications.
- Volume: 50 ml / 1000 ml
- High viscosity, single compound, especially for metal mechanical stress
- Especially for the flat metal surface bonding usage. Using it with an activator is required.
- It can fill the gaps and provide good vibration and impact resistance after being fully cured.
- For bonding different metal substrates, including metal, ferrite, and other motor components, it is the best metal bonding solution with the highest strength requirements.
- Volume: 50 ml / 300 ml
- Gel type, single compound, for high-temperature usage
- Low fluidity: for vertical surfaces, it can fill gaps. After curing, it provides excellent vibration and impact resistance.
- It can be cured by heating it above 130°C.
- High temperature resistance of 205°C: It is suitable for bonding motor components, such as metals or ferrites that come with high working temperatures.
- Volume: 50 ml / 300 ml
- Low viscosity, single compound, for metal and glass, fast curing
- Provides rapid bonding performance; cures within 1 minute when used with activator.
- Ideal for bonding gaps under 0.25 mm.
- Designed for rigid and flat substrates, delivering excellent adhesion with high resistance to heat distortion and impact.
- Offers fast and reliable bonding across various types of metals and glass, making it suitable for applications such as rearview mirror bracket attachment and glass ornament assembly.
- Volume: 50 ml / 1000 ml
Technical Information
|
Item No. |
Appearance |
Plastic |
Glass |
Metal |
Viscosity |
Gap Performance |
Shear Strength |
Working Temp |
Other / Heat Cure |
Activator |
|
31319 |
Amber liquid |
✔️✔️ | ✔️✔️ |
1,500–4,000 |
0.25mm / 5 min / 24 hrs |
≥10.2 |
-55 ~ 150 |
— |
017090 / 017649 |
|
|
31324 |
Amber liquid |
✔️ | ✔️ | ✔️✔️✔️ |
10,000–24,000 |
0.5–1mm / 5 min / 24 hrs |
15–21 |
-55 ~ 150 |
— |
037380 / 037387 |
|
31326 |
Amber liquid |
✔️ | ✔️✔️✔️ |
11,000–25,000 |
0.25mm / 2 min / 24 hrs |
≥15 |
-55 ~ 125 |
— |
017090 / 017649 |
|
|
31330 |
Slightly cloudy pale yellow |
✔️ | ✔️✔️✔️ |
45,000–90,000 |
0.5mm / 5 min / 24 hrs |
15–30 |
-55 ~ 125 |
— |
037380 / 037387 |
|
|
31332 |
Opaque yellow to amber |
✔️ | ✔️✔️✔️ |
75,000–130,000 |
0.5mm / 5 min / 24 hrs |
≥11 |
-55 ~ 200 |
20 min @130°C / 10 min @150°C |
037380 / 037387 |
